4805 Square End Plate – External & Lever Options

4805 Square End Plate – External & Lever Options

The Lockwood 4805 Square End Plate combines a slim rectangular plate with a range of lever options, designed for narrow stile applications in commercial, institutional, and high-traffic environments. This set is suitable for external doors and provides a clean, functional solution compatible with Lockwood mortice locks.

Features

• Slim-line rectangular brass plate with bevelled edges

• Lever Options: 112 series and multiple lever styles for ergonomic comfort

• External Plate: Concealed fixing (screws included), suitable for back-to-back installation

• Compliance: AS1428.1 for disabled access

• Material: Solid brass construction with durable finish options (Satin Chrome, Oil Rubbed Bronze, Powdercoat)

• Compatible with Lockwood Synergy 3580, Selector 3780, and 3540 Series short backset mortice deadbolts

• Plate Dimensions: 185 mm (H) × 26 mm (W) × 11.5 mm (D), Fixing Centres: 160 mm, Cylinder Pitch: 89.9 mm

• Lever Dimensions: Length 130.5 mm, Projection 48 mm, Finger Clearance 40 mm

• Door Thickness Range: 32–50 mm

Variants

EXT SQUARE END PLATE – Lever

• 112 — 4805/112ORB

• 101 — 4805/101ORB

• 102 — 4805/102ORB

• 123 — 4805/123ORB

• 124 — 4805/124ORB

• 131 — 4805/131ORB

• 101 — 4805/101AG

• 112 — 4805/112AG

• 104 — 4805/104AZ

• 70 — 4805/70AZ

• 115 — 4805/115CP

• 123 — 4805/123CP

• 145 — 4805/145CP

• 123 — 4805/123AU

• 178 — 4805/178AU

• 124 — 4805/124AC

• 111 — 4805/111AC

• 132 — 4805/132SB

• 155 — 4805/155SB

• 155 — 4805/155SBU

• 166 — 4805/166SBU

• 180 — 4805/180BU

• 180 — 4805/180PB

SQUARE END PLATE – Lever

• 101 — 4805/101PC

• 102 — 4805/102PC

• 104 — 4805/104PC

• 106 — 4805/106PC

• 111 — 4805/111PC

• 112 — 4805/112PC

• 115 — 4805/115PC

• 116 — 4805/116PC

• 118 — 4805/118PC

• 122 LH — 4805/122LPC

• 122 RH — 4805/122RPC

• 123 — 4805/123PC

• 124 — 4805/124PC

• 131 — 4805/131PC

SQUARE END PLATE – Lever (SC series)

• 101 — 4805/101SC

• 102 — 4805/102SC

• 104 — 4805/104SC

• 106 — 4805/106SC

• 111 — 4805/111SC

• 112 — 4805/112SC

• 115 — 4805/115SC

• 116 — 4805/116SC

• 118 — 4805/118SC

• 122 LH — 4805/122LSC

• 122 RH — 4805/122RSC

• 123 — 4805/123SC

• 124 — 4805/124SC

• 131 — 4805/131SC
